PA 2210 FR
Material Data Sheet
PA 2210 FR
Product Description
PA 2210 FR is a composition on the basis of polyamide 12 and a halogen-free flame retardant material. With its good mechanical properties and its outstanding fire properties it is mainly used in the electrical and electronics industry. PA 2210 FR is certified by Underwriters Laboratories (UL). Safety and quality are continuously tested by a third-party to ensure ongoing compliance, with an UL Recognized Component Mark on the product label. A growing market are railway applications, as PA 2210 FR fulfills several requirement sets according to EN 45545-2, the European railway standard for fire protection. The material is also used in aerospace industry, flammability compliance according to FAR 25.853 is tested for every material batch.
- Flame-retardant
- Halogen-free
- Fire classification UL 94/V-0
- UL certified - View Blue Card
- Fire classification FAR 25.853
- Electrical and electronic parts, e. g. housings
- Railway interiors, e. g. ventilation ducts
- Aircraft interiors, e. g. air valves
| MECHANICAL PROPERTIES | DRY / CONDITIONED | UNIT | TEST STANDARD |
|---|---|---|---|
|
Tensile Modulus X Orientation Y Orientation Z Orientation |
2500 / 2400 2500 / 2400 2300 / 2200 |
MPa MPa MPa |
ISO 527-1/-2 |
|
Tensile Strength X Orientation Y Orientation Z Orientation |
46 / 43 46 / 43 41 / 38 |
MPa MPa MPa |
ISO 527-1/-2 |
|
Strain at Tensile Strength X Orientation Y Orientation Z Orientation |
4 / 6 4 / 6 3 / 4 |
% % % |
ISO 527-1/-2 |
|
Strain at Break X Orientation Y Orientation Z Orientation |
4 / 7 4 / 7 3 / 4 |
% % % |
ISO 527-1/-2 |
|
Flexural Modulus X Orientation |
2300 / - |
MPa |
ISO 178 |
|
Flexural Strength X Orientation |
65 / - |
MPa |
ISO 178 |
| THERMAL PROPERTIES | DRY / CONDITIONED | UNIT | TEST STANDARD |
|---|---|---|---|
| Melting Temperature | 185 | °C | ISO 11357-1/-3 |
|
Temperature of Deflection under Load 1.80 MPa X Orientation Z Orientation |
95 108 |
°C °C |
ISO 75-1/-2 |
|
Temperature of Deflection under Load 0.45 MPa X Orientation Z Orientation |
165 170 |
°C °C |
ISO 75-1/-2 |
|
Flammability Test Passed, 12s ignition time Test Passed, 12s ignition time |
1.7 2.0 |
mm mm |
CS 25 / JAR25 / FAR 25 § 25-853 |
|
Smoke Density Test Passed Test Passed |
1.7 2.0 |
mm mm |
ABD 0031 (Issue:F), method: AITM 2.0007 |
|
Toxicity Test Passed Test Passed |
1.7 2.0 |
mm mm |
ABD 0031 (Issue:F), method: AITM 3.0005 |
|
Burning Behavior, 0.75 mm nom. Thickness Thickness Tested Blue Card Available |
HB 0.75 Yes |
class mm |
ANSI/UL 94, IEC 60695-11-10, -20 |
|
Burning Behavior, 3.0 mm nom. Thickness Thickness Tested Blue Card Available |
V-0 3.0 Yes |
class mm |
ANSI/UL 94, IEC 60695-11-10, -20 |
| ELECTRICAL PROPERTIES | DRY / CONDITIONED | UNIT | TEST STANDARD |
|---|---|---|---|
|
Comparative Tracking Index CTI X Orientation Y Orientation Z Orientation |
- / 425 - / 425 - / 450 |
|
IEC 60112 |
|
Electric Strength X Orientation Y Orientation |
- / 18.1 - / 18.1 |
kV/mm kV/mm |
IEC 60243-1 |
|
Volume Resistivity X Orientation Y Orientation |
- / 1E15 - / 1E15 |
Ohm•m Ohm•m |
IEC 62631-3-1 |
|
Surface Resistivity X Orientation Y Orientation |
- / 1E14 - / 1E14 |
Ohm Ohm |
IEC 62631-3-12 |
|
Dissipation Factor 100 Hz X Orientation Y Orientation |
- / 1013 - / 1013 |
E-4 E-4 |
IEC 62631-2-1 |
|
Dissipation Factor 1 MHz X Orientation Y Orientation |
- / 691 - / 691 |
E-4 E-4 |
IEC 62631-2-1 |
|
Relative Permittivity 100 Hz X Orientation Y Orientation |
- / 3.39 - / 3.39 |
|
IEC 62631-2-1 |
|
Relative Permittivity 1 MHz X Orientation Y Orientation |
- / 2.25 - / 2.25 |
|
IEC 62631-2-1 |
| OTHER PROPERTIES | VALUE | UNIT | TEST STANDARD |
|---|---|---|---|
| Density | 1.06 | g/cm³ | ISO 1183-1 |
| Powder Color | white | - | - |
| Components Color | white | - | - |
